Gas chromatography injector

TWELVE INJECTOR TYPES TO CHOOSE FROMTwelve injector types are available for installation on SRI gas chromatographs. Up to five injectors may be mounted simultaneously on the Model 8610C or 8610D. The Model 410 can mount a gas sampling valve in addition to the On-column injector which may be upgraded. The Model 310 will accommodate a single On-column, Heated Flash Vaporization, Heated Split/Splitless or PTV injector. Injector types are selected by the user depending on the particular measurement application, detection limit and regulatory requirements. The On-column injector is standard equipment on every 8610, 410 and 310 GC. Heated Flash Vaporization, Heated Split/Splitless and PTV injectors are all upgrades to the on-column injector. All injectors must be installed at the SRI factory. 1. On-column injector2. Heated flash vaporization injector3. Heated split/splitless injector4. PTV - programmable temperature vaporization injector5. 10-port gas sampling valves and 22-port stream selector valves6. Sample Preconcentration and Enrichment Options: Heated Adsorbent TrapsPermeation Loop AccessoryEnrichment Coils7. Method TO-14 Air Concentrator8. Thermal Desorber9. Method 5030/5035 compliant purge & trap; Method 5035 VOA vial purge head retrofit10. Heated Static Headspace Injector11. 120 vial liquid autosampler (with headspace tray option)12. 10-sample purge & trap Autosampler; Online sampler for purge & trap
